SBC with PICO-ITX Form-factor Based on i.MX8M Application Processor

Miniaturization of Board Design

Client Overview

US-based engineering and manufacturing company providing embedded computing solutions through a variety of products

Business Need

  • The client wanted to expand their product portfolio with the latest NXP i.MX8M Quad-core industrial-grade processor in PICO-ITX form factor

VOLANSYS Contribution

  • Designed and developed PICO-ITX form factor SBC (Single Board Computer) based on NXP’s i.MX8M platform
  • Finalized product specification and architecture design
  • Designed and developed hardware including schematics entry, PCB layout, Gerber, SI, and PI analysis release for final design
  • Developed firmware with Yocto Linux BSP integration
  • Engineering design validation and testing
  • Environmental testing for thermal (-40 to 85C), shock, and vibration
  • Pre-compliance and final compliance testing for FCC and CE

Solution Diagram

Form-factor design

Benefits Delivered

  • Delivered industrial-grade compliant solution with miniature board design just in 18 weeks, enabling faster time to market
  • Integration of the latest NXP module with the ability of high computing power enables their OEM partner to build industrial applications quickly
